Orange Pi R1 (512MB)

CPU

H3 Quad-core 32-bit Cortex-A7

GPU

Mali400MP2 GPU @600MHz, Supports OpenGL ES 2.0

Memory (SDRAM)

512MB DDR3 (shared with GPU)

Onboard Storage

TF card (Max. 32GB) / Spi flash(16MB)

Wifi Antenne

Yes

Onboard WIFI

Realtek RTL8189FTV, IEEE 802.11 b/g/n

Onboard Network

100M/10M Ethernet RJ45(Onboard Ethernet)

100M/10M Ethernet RJ45(RTL8152B)

Audio Input

No

Video Outputs

Supports external board via 13pins

Power Source

USB OTG can supply power

GPIO(1x3) pin

UART, ground.

Buttons

Power Button(SW602)

Low-level peripherals

26 Pins Header

13 Pins Header, with 2x USB, IR pin, AUDIO(MIC, AV)

LED

Power led & Status led

Supported OS

Android4.4, Lubuntu, Debian, Armbian Image

Interface definition

Product size

45 mm × 60mm

Weight

35g
